CruzPro V60 Voltmeter for 3 Groups

(0)
€ 238,67 € 251,23
iva inclusa
Code: MTO02085
quantity
Print

The CruzPro V60 is a digital reading voltmeter capable of displaying the voltage from 9.5 to 33 Vdc of 3 groups of different batteries. It is possible to set independent high and low voltage alarms for each group of batteries and if the reading leaves these values the V60 will emit an alarm at 85 dB while the display will flash. 5 backlight levels are selectable. Each setting will be stored in a non-volatile memory. Power supply 12/24 Vdc. NMEA 0183 output.

All calibrations are set by the parent company, but can be changed by the user at any time. Low / high voltage alarms can be set independently and can be activated or deactivated with the press of a button.

Technical features

  • Supply voltage: 9.5 - 33 Vdc
  • Absorption: 0.018 Nominal amps
  • Display: 3 digits, 5 backlight levels
  • Data displayed: Volt, low and high voltage alarm
  • Reading range: 9.5 - 33.0 Vdc
  • NMEA 0183 serial output at 4800 bps ($ IIXDR, V judgment)
  • Alarm: Integrated from 85 dB, Settable as minimum and / or maximum voltage
  • Recessed hole: 55 mm
