CruzPro T60 Engine Water / Oil Temperature

The T60 is a digital indicator for the temperature of the water or engine oil. Compatible with the most common temperature sensors from 15 to 250 ohm such as those of VDO, Teleflex, Faria, Stewart-Warner and many others. (The sensor is not included) The type of sensor installed is easily selectable from the front panel. The high or low temperature alarms can be set on the entire sensor reading scale. When the alarm is activated the meter will sound an alarm at 85 dB and the display will flash. All settings, calibrations and alarm values are saved in a non-volatile memory.

By pressing a button it is possible to view the temperature (° C or ° F) and the alarm values for high and low temperatures. Using the NMEA 0183 4800 bps standard, the detected data can be sent to a NMEA repeater such as the CruzPro RP30, RP110, MaxRP110 and MaxVu110. It is also possible to set this port as an external alarm output. The instrument absorbs only 0.018 Ampere and it is possible to select 5 levels of backlighting including "OFF".

Technical features

• Power supply voltage: 9.5 - 33 Vdc
• Display: 4 digits, 5 backlight levels
• Absorption: 0.018 amps nominal
• Data: Temperature from 0 to 150 ° C (32 to 300 ° F) +/- 0.5 °
• Input: All popular temperature sensors
• Output: NMEA 0183 serial at 4800 bps. It can also be used as an external alarm output.
• Alarm: Integrated 85 dB, Settable as minimum and / or maximum temperature
• Embedding hole: 55 mm
