CruzPro F60 Economic Fuel Level

The CruzPro F60 via digital display provides the fuel level reading. The level can be displayed in Liters / Gallons or as a percentage (0-100%) up to 999 Gallons / Liters. It also displays partial, total and remaining fuel consumed. Readings can be taken in liters, gallons or as a percentage. The high and low fuel level alarm, user selectable, is very useful. It works with common level sensors such as 91005 and 91007. Supply voltage 12/24 Vdc. NMEA 0183 output or external alarm output, which can also be used to control a fuel transfer pump.

Technical features

• Supply voltage: 9.5 - 33 Vdc
• Display: 4 digits, 5 backlight levels
• Absorption: 0.018 Nominal amps
• Displays the fuel level in Liters, Gallons or as a percentage
• Input: All popular American and European resistive sensors with 0-30, 0-70, 0-90, 10-73, 10-180, 33-240, 40-250 ohm (and vice versa) such as GM, VDO, Teleflex , Faria, Centroid, Aerotech, Stewart-Warner, etc.
• Outputs / External alarm: An output terminal can be used as NMEA 0183 output, as an external alarm output or as a control for a fuel transfer pump.
• NMEA 0183 serial output at 4800 bps ($ IIXDR ruling)
• Alarm: Integrated 85 dB
• Fuel transfer control pump: Programmable to start an optional pump when the fuel level reaches a pre-established minimum; Programmable to stop an optional pump when the fuel level reaches a pre-established maximum
• Recessed hole: 55 mm
