CruzPro CT60 Race Watch and Timer

The CT60 is a Clock and Race Timer with digital display reading. When connected via NMEA 0183 to a GPS or chart plotter, it updates the time independently. With the press of a button it will be possible to check the time or view and operate on the Tare Timer. It is possible to select up to 8 different alarms, set the 12/24 hour format and the maximum possible error is 1 second per day.

The Race Timer function is programmable with time intervals from 1 second to 99 minutes and 59 seconds. Pressing the down arrow key, the programmed time will be displayed and the countdown will begin. At the end of the time the instrument will emit an alarm at 85 dB. All other functions are available in Race Timer mode.

The calibrations are carried out by the house, but the user can modify them according to every need. All settings, calibrations and alarm values are saved in a non-volatile memory. The detected data can be sent via standard NMEA 0183 4800 bps interface to other devices or repeaters such as the CruzPro RP30 and RP110.

Technical features

• Supply voltage: 9.5 - 33 Vdc
• Display: 4 digits, 5 backlight levels
• Absorption: 0.018 Nominal amps
• Operating temperature: from 0 ° to 50 ° C
• Data: Time, Programmable Race Timer
• Time format: 12 or 24
• Resolution: Better than 1 second per day
• GPS input: Auto time correction via NMEA 0183
• Output: NMEA 0183 serial at 4800 bps
• Recessed hole: 55 mm
